At Nasir Nickel Alloys in Manama, Bahrain, Duplex Steel 2205 Forged Fittings are engineered to deliver superior corrosion resistance, high strength, and durability for critical piping systems. Made from duplex stainless steel with a balanced austenitic-ferritic microstructure, these fittings resist pitting, crevice corrosion, and stress-corrosion cracking, particularly in chloride-rich and chemically aggressive environments. The forged construction ensures enhanced mechanical properties and dimensional stability. Designed for demanding industrial applications, Duplex Steel 2205 Forged Fittings provide leak-tight performance and long-term reliability, making them ideal for chemical, petrochemical, oil and gas, marine, and offshore industries.
Duplex Steel 2205 Forged Fittings are composed of chromium, nickel, molybdenum, and nitrogen, forming a balanced austenitic-ferritic structure. This composition offers high tensile and yield strength, excellent toughness, and superior resistance to pitting, crevice corrosion, and stress-corrosion cracking. The forging process further enhances mechanical integrity and dimensional stability, allowing the fittings to withstand thermal cycling, high pressure, and mechanical stress. Duplex Steel 2205 Forged Fittings combine durability, corrosion resistance, and mechanical strength, ensuring leak-tight, reliable performance in demanding chemical and industrial piping systems where conventional stainless steel may fail.
| 2205 Duplex Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Duplex 2205 Pipe Fittings size | Seamless 2205 Duplex Stainless Butt Weld Fittings: 1/2″ – 10″ Welded 2205 Stainless Steel Butt Weld Fittings: 1/2″ – 48″ |
| Specifications | ASTM A815 / ASME SA815 |
| Duplex 2205 Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Duplex 2205 Forged Fittings Thread | NPT, BSPT, BSPP |
| ASTM A815 Fittings Type | DN15-DN1200 |
| 2205 Duplex Pipe Fittings Types | Seamless / ERW / Welded / Fabricated Duplex 2205 Werkstoff 1.4462 Pipe Fittings |
| Fitting Duplex 2205 Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Avesta 2205 Pipe Fittings |
| Duplex 2205 Forged Fittings Pressure Rating | Threaded end-2000lb/ 3000lb/ 6000lbs 2205 Duplex 1.4462 Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs 2205 Duplex Stainless Steel Pipe Fittings |
| Fitting Duplex 2205 Size Range | 1/2″ NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Duplex 2205 F51 Pipe Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Key markets and industries for 22cr Fitting Duplex 2205 |
|
| Duplex 2205 Elbow | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Equal Tees & Reducing Tees,Couplings, Reducers, Inserts, Unions, Caps, Nipples, Forged Pipe Fittings, Socket Weld & Threaded, 90° & 45° Elbows – Female-Female, Male-Male, Male-Female, Union, Nipples, Couplings, Plugs Fittings |
| 2205 Duplex Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA815 Material End |
|
| F51 2205 Duplex Pipe Fittings uses & application |
|
| 2205 Duplex Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian (NO CHINA) |
| Material Test Certificates (MTC) for Duplex 2205 Fittings as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
|---|---|---|---|---|---|---|---|---|---|
| 1.0 | 0.03 | 0.02 | 2.0 | 3.0 – 3.5 | 22.0 – 23.0 | 0.03 | 4.5 – 6.5 | 0.14 – 0.2 | Bal |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel 2205 Forged Fittings in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel 2205 Forged Fittings are extensively used in industries requiring corrosion-resistant, high-strength, and durable piping solutions. They are critical in chemical and petrochemical plants for pipelines, reactors, and heat exchangers handling acids, alkalis, and chlorides. Oil and gas industries employ these fittings in pumps, critical piping assemblies, and process control systems. Power generation and desalination plants benefit from their ability to withstand high temperature and pressure. Offshore and marine applications utilize Duplex Steel 2205 Forged Fittings in seawater pipelines and process systems. These fittings provide secure, long-lasting, and reliable connections for critical piping networks in harsh environments.
