Haynes 25 / L605 Foil is a top-notch alloy foil made from cobalt, chromium, tungsten, and nickel, celebrated for its remarkable strength at high temperatures, resistance to oxidation, and impressive durability over time. As a premier manufacturer and supplier of Haynes 25 / L605 Foil in Manama, Bahrain, we specialize in precision-rolled foils designed for the toughest aerospace, industrial, and chemical applications. This alloy stands out for its exceptional resistance to carburization, sulfidation, and thermal fatigue, making it perfect for components that face extreme heat and corrosive conditions. Crafted with meticulous attention to dimensional accuracy and a superb surface finish, our Haynes 25 / L605 Foils ensure dependable performance in critical, high-stress environments.
Haynes 25 / L605 Foil is primarily made up of cobalt, chromium, nickel, and tungsten, with added carbon, manganese, and silicon to boost its strength and stability. This alloy showcases outstanding oxidation resistance up to 1095°C, along with remarkable creep and fatigue resistance. In terms of mechanics, it boasts excellent tensile and yield strength, high hardness, and good ductility, even at elevated temperatures. The foil retains its structural integrity during intense thermal cycling and demonstrates strong resistance to corrosion and wear, guaranteeing long-lasting performance in demanding operating conditions.
| Standard Specification : | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat T |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Haynes 25 / L605 Foil is extensively utilized in scenarios that demand ultra-thin, high-strength materials capable of enduring extreme temperatures and corrosive environments. Typical applications include combustion chamber liners, turbine engine insulation, thermal barriers, aerospace shielding, and high-temperature gaskets. In industrial settings, it finds use in furnace components, catalytic converter parts, heat-treatment equipment, and chemical processing systems. Its excellent resistance to oxidation and sulfidation makes it ideal for environments with hot gases, high-pressure steam, and corrosive chemicals.
