At Nasir Nickel Alloys in Manama, Bahrain, Incoloy 800/800H/800HT Tube Fittings are engineered to deliver exceptional corrosion resistance, high-temperature stability, and mechanical strength for demanding industrial applications. Manufactured from nickel-iron-chromium alloys with controlled carbon and additional alloying elements, these fittings provide superior resistance to oxidizing and reducing environments, thermal fatigue, and creep at elevated temperatures. Each fitting is precision-crafted to ensure leak-proof, secure connections and reliable performance. Designed for chemical, petrochemical, power generation, and high-temperature systems, Incoloy 800/800H/800HT Tube Fittings offer dependable solutions for long-term, high-temperature, and corrosive service applications.
Incoloy 800/800H/800HT Tube Fittings are composed primarily of nickel, iron, and chromium, with controlled carbon levels and additions of manganese, silicon, and copper depending on the grade. The 800H and 800HT grades feature higher carbon content to enhance strength at elevated temperatures. Mechanically, the fittings offer high tensile and yield strength, excellent creep and fatigue resistance, and reliable toughness under thermal cycling and high-pressure conditions. The alloy maintains dimensional stability and structural integrity under prolonged exposure to heat and corrosive media, ensuring dependable performance in high-temperature and industrial applications.
| ASME B1.1 Materials Standard & Specification |
|
||||||
| PSI Pressure Ratings |
|
||||||
| Incoloy 825 Tube Fittings and Adapter Fittings Maximum Allowable Working Product Pressure |
|
||||||
| Alloy | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Tube Fittings | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Tube Fittings | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Tube Fittings in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Tube Fittings are widely used in industries requiring high-temperature corrosion resistance, mechanical strength, and durability. They are ideal for heat exchangers, furnace components, chemical and petrochemical processing equipment, nuclear power systems, and high-temperature piping networks. Their resistance to oxidizing and mildly reducing environments, thermal fatigue, and creep makes them suitable for long-term service at elevated temperatures. These fittings also perform reliably in high-pressure and chemically aggressive applications. By providing leak-proof, durable connections and consistent performance under extreme conditions, Incoloy 800/800H/800HT Tube Fittings ensure safe, efficient, and long-lasting operation across industrial, chemical, and power generation systems.
