At Nasir Nickel Alloys in Manama, Bahrain, Incoloy 825 Tube Fittings are engineered to provide exceptional corrosion resistance, mechanical strength, and long-term reliability in the most demanding industrial environments. Manufactured from a nickel-iron-chromium alloy with additions of molybdenum and copper, these fittings deliver superior protection against oxidizing and reducing agents, acids, and chloride-induced corrosion. Each fitting is precision-crafted to ensure leak-proof, secure connections and consistent performance. Designed for chemical, petrochemical, marine, and power generation systems, Incoloy 825 Tube Fittings offer dependable solutions for high-pressure and highly corrosive applications, ensuring safe, efficient, and long-lasting operation.
Incoloy 825 Tube Fittings are composed primarily of nickel, iron, and chromium, with molybdenum and copper additions to enhance corrosion resistance and mechanical stability. This composition provides outstanding resistance to strong acids, oxidizing and reducing agents, and chloride-induced corrosion. Mechanically, the fittings exhibit high tensile and yield strength, excellent toughness, and reliable fatigue and creep resistance under fluctuating pressures and elevated temperatures. The alloy maintains dimensional stability and resists stress corrosion cracking, ensuring long-term performance. These properties make Incoloy 825 Tube Fittings ideal for demanding chemical, marine, and high-pressure industrial applications.
| ASME B1.1 Materials Standard & Specification |
|
||||||
| PSI Pressure Ratings |
|
||||||
| Incoloy 825 Tube Fittings and Adapter Fittings Maximum Allowable Working Product Pressure |
|
||||||
| Alloy | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Tube Fittings | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Tube Fittings | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Tube Fittings in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Tube Fittings are widely used in industries requiring superior corrosion resistance, mechanical strength, and high-temperature performance. They are ideal for chemical processing units, petrochemical plants, acid production systems, desalination facilities, and marine applications. Their resistance to oxidizing and reducing agents, strong acids, and chloride-induced corrosion makes them suitable for aggressive industrial environments. These fittings also perform reliably in high-pressure pipelines, heat exchangers, and process equipment handling harsh chemicals. By providing secure, leak-proof connections and consistent performance, Incoloy 825 Tube Fittings ensure safe, efficient, and long-lasting operation across chemical, petrochemical, marine, and industrial applications.
