At Nasir Nickel Alloys in Manama, Bahrain, Incoloy Stud Bolts are engineered to provide exceptional performance in environments where high temperatures, corrosion, and mechanical stress are part of daily operations. These nickel-iron-chromium alloys are crafted to deliver long-term stability, making them ideal for applications exposed to oxidizing and carburizing conditions. Their robust structure allows them to maintain strength even during thermal cycling or prolonged exposure to elevated temperatures. Incoloy Stud Bolts offer dependable fastening solutions for industries that require durable, corrosion-resistant hardware capable of performing reliably in challenging and demanding conditions.
Incoloy Stud Bolts are composed primarily of nickel, iron, and chromium, with specific grades containing controlled amounts of titanium, aluminum, carbon, and other strengthening elements. This composition gives the alloy excellent thermal stability, resistance to oxidation, and impressive mechanical strength at elevated temperatures. These stud bolts demonstrate high tensile and yield strength, excellent creep resistance, and the ability to withstand carburizing and corrosive environments. Their metallurgical stability ensures consistent performance under heavy loads, thermal stress, and fluctuating operating conditions.
| Specification | ASTM F468, B425 / ASME SF468, SB425 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Stud Bolts in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy Stud Bolts are widely used across industries that operate under extreme heat, corrosive chemicals, or high stress. Petrochemical plants rely on them for furnace parts, heaters, reformer tubes, and cracking units. Power generation facilities use them in boilers, superheater systems, and high-temperature ducting. Chemical processing units benefit from their corrosion resistance in reactors, piping systems, and pressure vessels. These stud bolts also perform well in heat treatment equipment, thermal oxidizers, and refinery operations. Their combination of strength, durability, and resistance to harsh environments makes them essential for long-term, high-performance fastening applications.
