At Nasir Nickel Alloys in Manama, Bahrain, Monel 400 Sheets and Plates are engineered to deliver exceptional corrosion resistance, strength, and durability in demanding industrial environments. Manufactured from a high-quality nickel-copper alloy, they offer superior performance in seawater, chemical exposure, and extreme temperature conditions. Each sheet and plate is precision-rolled and finished to ensure consistent thickness, surface quality, and structural integrity. Designed for applications that require long-term reliability and resistance to harsh media, Monel 400 Sheets and Plates provide a versatile solution for marine, chemical, and industrial systems that demand durability, performance, and corrosion protection.
Monel 400 Sheets and Plates are composed primarily of nickel and copper, with small amounts of iron and manganese to enhance mechanical strength and stability. This alloy exhibits outstanding resistance to corrosion in seawater, acids, and alkaline environments. Mechanically, Monel 400 offers high tensile strength, excellent toughness, and reliable ductility across a wide temperature range. It maintains structural integrity under thermal cycling, fluctuating loads, and mechanical stress. The combination of corrosion resistance, strength, and durability ensures that these sheets and plates perform reliably in critical industrial applications.
| Specifications | ASTM / ASME SB 127 |
|---|---|
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel 400 Sheet and Plates in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel 400 Sheets and Plates are widely used in industries that demand resistance to corrosion, chemical attack, and mechanical stress. They are ideal for marine applications, shipbuilding, offshore platforms, desalination plants, and chemical processing equipment. Their resistance to seawater and acidic or alkaline media makes them suitable for heat exchangers, tanks, pressure vessels, and piping systems. Monel 400 Sheets and Plates are also employed in pumps, valves, and other components where structural stability and durability are essential. By providing long-lasting performance under harsh conditions, they support safe, efficient, and reliable operation across a broad range of industrial applications.
