At Nasir Nickel Alloys in Manama, Bahrain, Monel K500 Sheets and Plates are engineered to provide exceptional corrosion resistance, high mechanical strength, and long-term durability for demanding marine, chemical, and industrial applications. Manufactured from a nickel-copper alloy with additions of aluminum and titanium, these sheets and plates offer superior resistance to seawater, brackish water, acids, and alkalis while maintaining excellent structural integrity. Precision-engineered for uniform thickness and consistent performance, Monel K500 Sheets and Plates are ideal for chemical processing, petrochemical, marine, and high-pressure systems, delivering reliable, durable, and efficient solutions for aggressive and corrosive environments.
Monel K500 Sheets and Plates are composed primarily of nickel (approximately 63–70%) and copper (approximately 28–34%), with small additions of aluminum and titanium for age-hardening and enhanced mechanical strength. This composition provides outstanding resistance to seawater, brackish water, acids, and alkalis, as well as excellent pitting and stress corrosion resistance. Mechanically, these sheets and plates offer high tensile and yield strength, toughness, and fatigue resistance under fluctuating pressures and thermal cycling. The combination of superior corrosion resistance and mechanical robustness ensures long-term reliable performance in marine, chemical, and industrial applications.
Specifications :ASTM B127 / ASME SB127, AMS 4544
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 4000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28 – 34 | 2.50 max | 63.00 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Sheet and Plates in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel K500 Sheets and Plates are widely used in industries requiring high corrosion resistance, mechanical strength, and long-term durability. They are ideal for seawater piping, desalination plants, heat exchangers, marine structures, chemical processing equipment, and petrochemical facilities. Their resistance to seawater, brackish water, acids, and alkalis makes them suitable for offshore platforms, high-pressure components, and industrial equipment exposed to harsh environments. These sheets and plates provide a reliable base for fabricating high-strength, corrosion-resistant components. By delivering consistent, long-term performance in aggressive conditions, Monel K500 Sheets and Plates ensure safe, efficient, and durable operation across marine, chemical, and industrial applications.
