At Nasir Nickel Alloys in Manama, Bahrain, Monel Sheets and Plates are engineered to provide exceptional corrosion resistance, mechanical strength, and long-term durability for demanding industrial, marine, and chemical applications. Manufactured from high-quality nickel-copper alloys, these sheets and plates deliver superior resistance to seawater, brackish water, acids, and alkalis while maintaining structural integrity and uniform thickness. Precision-engineered for reliable performance, Monel Sheets and Plates are ideal for chemical, petrochemical, marine, and power generation systems. They provide dependable, long-lasting solutions in aggressive environments, ensuring safe, efficient, and high-performance operation for critical industrial applications.
Monel Sheets and Plates are primarily composed of nickel (approximately 67%) and copper (approximately 33%), with minor additions of iron and manganese to enhance strength and corrosion resistance. This composition provides outstanding performance in seawater, brackish water, and chemically aggressive environments, resisting pitting, stress corrosion cracking, and erosion. Mechanically, they offer high tensile and yield strength, excellent toughness, and reliable fatigue resistance under fluctuating pressures and thermal cycling. The combination of corrosion resistance and mechanical robustness ensures Monel Sheets and Plates deliver long-term, reliable performance in marine, chemical, and industrial applications.
Specifications :ASTM B127, ASME SB127, AMS 4544, QQ-N-281, DIN 17750, BS 3072NA1, BS 3076NA13
Standards : ASTM, ASME and API
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness : 0.1mm to 12 mm Thk
Length : 12500 mm
Form : Coils, Foils, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) & Angle, Channel, Tray Etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Plate, Sheet, and Strip : BS3072NA18 (Sheet and Plate), BS3073NA18 (Strip), QQ-N-286 (Plate, Sheet and Strip), DIN 17750 (Plate, Sheet and Strip), ISO 6208 (Plate, Sheet and Strip)
Grade : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S |
|---|---|---|---|---|---|---|---|---|
| Monel 400 | 63.0 min | 1.0 – 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.50 max | 0.02 max |
| Monel K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.010 max |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Sheet and Plates in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Sheets and Plates are widely used in industries requiring superior corrosion resistance, mechanical strength, and durability. They are ideal for seawater piping, desalination plants, heat exchangers, chemical processing units, petrochemical facilities, and marine structures. Their resistance to seawater, acids, alkalis, and brackish water makes them suitable for offshore platforms, high-pressure components, and industrial equipment exposed to harsh environments. These sheets and plates provide a reliable base for manufacturing corrosion-resistant and high-strength components. By ensuring leak-proof, durable performance in aggressive conditions, Monel Sheets and Plates enable safe, efficient, and long-lasting operation across chemical, petrochemical, marine, and industrial applications.
