Nasir Nickel Alloys supplies Nickel Alloy Flanges manufactured to high standards such as ASTM B564 / ASME SB564. These flanges come in various types including weld neck, slip-on, threaded, socket weld, blind, reducing, and lap joint flanges. They range in size from 1/2″ to 60″ and are available in various pressure classes like 150#, 300#, 600#, 900#, 1500#, and 2500#, suitable for industrial and aerospace applications.
The nickel alloy flanges are made from high-purity nickel grades like Nickel 200 and Nickel 201, known for excellent corrosion resistance in reducing environments including caustic alkalis, sulfuric and hydrochloric acids. They offer good mechanical strength even at elevated temperatures and maintain performance in steam, moist air, and harsh chemical exposure. These flanges meet international standards including ANSI/ASME B16.5, B16.47, B16.48, BS4504, BS10, DIN, and EN, ensuring broad compatibility and reliable performance.
| Dimensions | ASTM B564 / B182 |
| Grades | Nickel Alloy |
| Size | 1/8″ NB TO 48″ NB. |
| Class | 150#, 300#, 400#, 600#, 900#, 1500#, 2500#, 3000#. Also as per the National & International Standard. |
| Standard | SORF, SOFF, SOLJ, SWFF, WNRF, WNFF, WNRTJ, LWNRF, BLRF, BLFF, BLRTJ, SWRF, LAP Joint, Threaded, Reducing, Spectacle, Orifice & Studding Outlet are manufactured according to ANSI B 16.5, B 16.47 Series A (MSS SP-44), B 16.47 Series B (API 605), MSS SP-43, DIN 2527, DIN 2566, DIN 2576, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2642, BS 10, IS 1538 & IS 6392, etc |
| Types of Flanges | Weld neck Flanges (WNRF), Slip-on Flanges (SORF), Blind Flanges (BLRF), Lap Joint Flanges, (SOLJ), Socket-weld Flanges (SWRF), Screwed (Threaded) Flanges, Long weld neck Flanges (LWNRF), Spectacle Blind Flanges, Spacer & Blind Flanges, Ring Type Joint Flanges (RTJ), Reducing Flanges, Raised Face (RF) Flanges, Orifice Flanges, Deck Flange, Large Diameter Flanges, Custom Flanges, Drawing Flanges, Forged Flanges, Plate Flanges, Flat Face Flanges, etc. |
| Form | Slip-On Flange (SO), Blind Flange (BL), Lap Joint Flange (LF), Socketweld Flange (SW), Weld Neck Flange (WN), Long Weld Neck Flange (LWN), Ring Type Joint (RTJ), Threaded Flange, Customized Flange with Raised Face (RF), Flat Face (FF). |
| C | Mn | Si | S | Cu | Fe | Ni | |
| Nickel | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel Alloys | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy Flanges in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Nickel Alloy Flanges are widely used in chemical processing, power plants, aerospace, and marine industries where resistance to corrosion, heat, and mechanical stress is essential. Custom sizes and specifications can be provided to meet specific project requirements, making them versatile and dependable components for critical piping and equipment systems.
