Home > Super Duplex Steel > Super Duplex Steel S32750 Forged Fittings
At Nasir Nickel Alloys in Manama, Bahrain, Super Duplex Steel S32750 Forged Fittings are developed to deliver exceptional strength, corrosion resistance, and reliability in the most demanding industrial environments. Engineered with a balanced duplex microstructure, these fittings provide superior durability and stability where conventional materials may fall short. Each fitting is carefully crafted to ensure secure connections, consistent functionality, and long-term service life. With a strong focus on real-world performance, these forged fittings support operations that require robust components capable of withstanding harsh chemicals, high pressures, and challenging temperatures.
Super Duplex Steel S32750 Forged Fittings are produced from a high-performance alloy containing elevated levels of chromium, molybdenum, and nitrogen, offering excellent resistance to pitting, crevice corrosion, and stress corrosion cracking. The duplex structure enhances mechanical strength, delivering high tensile and yield values while maintaining reliable toughness. These fittings perform effectively under fluctuating pressures and elevated temperatures, ensuring stability and minimizing the risk of failure. Their exceptional corrosion resistance and strength-to-weight ratio make them suitable for demanding environments requiring both chemical durability and mechanical reliability.
| Specifications | ASTM A182 & ASME SA182 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socketweld Fittings |
| Grades | S32750 / S32760/ S32950 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
| Grades | Density (g/cm 3) | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| S32750 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15% |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Cu |
| S32750 | 0.030max | 1.20 max | 0.80 max | 0.035max | 0.020 max | 24.0-26.0 | 3.0-5.0 | 6.0-8.0 | 0.24/0.32 | 0.50 |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel S32750 Forged Fittings in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel S32750 Forged Fittings are ideal for operations that demand superior resistance to corrosive and high-stress conditions. They are used extensively in offshore platforms, subsea pipelines, chemical and petrochemical processing plants, and desalination units. Their outstanding resistance to seawater and chloride-induced corrosion makes them highly suitable for marine and coastal applications. These fittings also perform reliably in power generation systems, high-pressure flow lines, heat exchangers, and industrial processing equipment. By offering stable, long-lasting performance under harsh environments, they help ensure safe, efficient, and uninterrupted operations across a wide range of critical industries.
